C&K Components
7305SYZQE的详细信息
| Datasheets： | |
|---|---|
| 7000 Series Miniature Toggle Switches： | |
| Product Photos： | |
| 7301SYZQE, 7303SYZQE, 7305SYZQE： | |
| Product Training Modules： | |
| Introduction to Electromechanical Switches： | |
| Catalog Drawings： | |
| S Toggle Actuator： | |
| Y Bushing Top： | |
| Y Bushing Side： | |
| PCN Assembly/Origin： | |
| Series Transfer 26/Nov/2012： | |
| Standard Package ： | 1 |
| Category： | Switches |
| Family： | Toggle Switches |
| Series： | 7000 |
| Packaging ： | Bulk |
| Circuit： | 3PDT |
| Switch Function： | Mom-Off-Mom |
| Current Rating： | 5A (AC/DC) |
| Voltage Rating - AC： | 120V |
| Voltage Rating - DC： | 28V |
| Actuator Type： | Standard Round |
| Actuator Length： | 10.67mm |
| Illumination： | Non-Illuminated |
| Illumination Type, Color： | - |
| Illumination Voltage (Nominal)： | - |
| Mounting Type： | Panel Mount |
| Panel Cutout Dimensions： | Circular - 6.35mm Dia |
| Termination Style： | Solder Lug |
| Bushing Thread： | 1/4-40 |
| Ingress Protection： | - |
| Features： | Epoxy Sealed Terminals |
| Actuator Material： | Brass, Chrome Plated |
| Electrical Life： | 40,000 Cycles |
| Operating Temperature： | -30°C ~ 85°C |
| Dynamic Catalog： | 7000 Series |
| Associated Product： | CKN10357-ND - BOOT FULL TOGGLE 1/4-40 BLACKCKN10317-ND - HDWR LOCKWASHER 1/4"-40 BLACKCKN10316-ND - HDWR MTG NUT BLACK FOR 7000 SERCKN10080-ND - CAP TOGGLE BAT BLACK335-1036-ND - BOOT FULL TOGGLE 1/4-40 GRAYCKN1817-ND - HDWR SW LOCKING RING 1/4"BUSHINGCKN1756-ND - HDWR NUT KNURL 1/4"-40 .062"NKLCKN1755-ND - HDWR NUT KNURL 1/4"-40 .080" NKLCKN1392-ND - HDWR DRESS NUT 1/4-40 .090" NKLCKN1754-ND - HDWR DRESS NUT 1/4"-40 .118"H706203000-ND - CAP TOGGLE BAT RED706201000-ND - CAP TOGGLE BAT WHITECKN1205-ND - CAP TOGGLE BAT REDCKN1204-ND - CAP TOGGLE BAT BLACKCKN1203-ND - CAP TOGGLE BAT WHITECKN1393-ND - HDWR DRESS NUT1/4-40 SATIN CHROMCKN1185-ND - HDWR MTG NUT .062" FOR 7000 SERCKN1753-ND - HDWR LOCKWASHER 1/4"-40 BUSHINGCKN1201-ND - HDWR NUT DRESS .25" .118"H NKL |
| Other Names： | *7305SYZQECKN1136 |
