54809-4598的详细信息
| Datasheets： | |
|---|---|
| 54809-4598： | |
| Product Photos： | |
| 54809-4598-C： | |
| RoHS Information： | |
| 54809-4598 Cert of Compliance： | |
| 3D Model： | |
| 54809-4598.stp： | |
| Standard Package ： | 2,500 |
| Category： | Connectors, Interconnects |
| Family： | FFC, FPC (Flat Flexible) Connectors |
| Series： | Easy-On™ 54809 |
| Packaging ： | Tape & Reel (TR) |
| Flat Flex Type： | FPC |
| Mounting Type： | Surface Mount, Right Angle |
| Connector/Contact Type： | Contacts, Bottom |
| Number of Positions： | 45 |
| Pitch： | 0.012" (0.30mm) |
| Termination： | Solder |
| FFC, FCB Thickness： | 0.20mm |
| Height Above Board： | 0.051" (1.30mm) |
| Locking Feature： | Flip Lock |
| Cable End Type： | Tapered |
| Contact Material： | Phosphor Bronze |
| Contact Finish： | Tin Bismuth |
| Housing Material： | Liquid Crystal Polymer (LCP) |
| Actuator Material： | Polyamide (PA46), Nylon 4/6 |
| Features： | Solder Retention, Zero Insertion Force (ZIF) |
| Voltage Rating： | 50V |
| Operating Temperature： | -20°C ~ 85°C |
| Material Flammability Rating： | UL94 V-0 |
| Current Rating： | 0.3A |
| Other Names： | 054809-45980548094598 |
