型号: | 52408 |
厂商: |
TE Connectivity |
标准: | |
分类: | 连接器 , 端子 - 铲形连接器 |
描述: | conn spade spring 22-16awg #4 |
报错 收藏 赞 |
52408的详细信息
Datasheets: | |
---|---|
52408: | |
RoHS Information: | |
52408 Statement of Compliance: | |
RoHS 2 Statement: | |
Standard Package : | 10,000 |
Category: | Connectors, Interconnects |
Family: | Terminals - Spade Connectors |
Series: | PIDG, AMP |
Packaging : | Bulk |
Terminal Type: | Spring, Snap |
Stud/Tab Size: | 4 Stud |
Width - Outer Edges: | 0.203" (5.16mm) |
Length - Overall: | 0.896" (22.76mm) |
Mounting Type: | Free Hanging (In-Line) |
Termination: | Crimp |
Wire Gauge: | 16-22 AWG |
Insulation: | Insulated |
Features: | Serrated Termination |
Color: | Red |
Contact Finish: | Tin |
Contact Material: | Phosphor Bronze |
Insulation Diameter: | 0.080" ~ 0.125" (2.03mm ~ 3.18mm) |
Material - Insulation: | Polyamide (PA), Nylon |
Length - Ring Center to Termination: | 0.201" (5.11mm) |
Length - Termination: | 0.414" (10.52mm) |
Tongue Inside Opening: | 0.112" (2.84mm) |
Associated Product: | 69151-1-ND - TOOL HAND PIDG S EXP 16-22AWG47386-5-ND - HAND TOOL PIDG 16-26AWG217202-1-ND - T-HEAD CRIMPER NORM CLOSEDA27484-ND - HAND TOOL PIDG 16-26AWGA9811-ND - TOOL CRIMP INSUL TERM W/DIE SETA9991-ND - DIESET SPLICE TERMINALS |
