Molex
5022505191的详细信息
| Datasheets： | |
|---|---|
| 5022505191： | |
| RoHS Information： | |
| 5022505191 Cert of Compliance： | |
| 3D Model： | |
| 502250-5191.stp： | |
| 502250-5191 .pdf： | |
| Standard Package ： | 3,000 |
| Category： | Connectors, Interconnects |
| Family： | FFC, FPC (Flat Flexible) Connectors |
| Series： | BackFlip™, Easy-On™ 502250 |
| Packaging ： | Tape & Reel (TR) |
| Flat Flex Type： | FPC |
| Mounting Type： | Surface Mount, Right Angle |
| Connector/Contact Type： | Contacts, Top and Bottom |
| Number of Positions： | 51 |
| Pitch： | 0.012" (0.30mm) |
| Termination： | Solder |
| FFC, FCB Thickness： | 0.20mm |
| Height Above Board： | 0.036" (0.90mm) |
| Locking Feature： | Flip Lock, Backlock |
| Cable End Type： | Notched or Tabbed |
| Contact Material： | Copper Alloy |
| Contact Finish： | Gold |
| Housing Material： | Liquid Crystal Polymer (LCP), Glass Filled |
| Actuator Material： | Polyphenylene Sulfide (PPS), Glass Filled |
| Features： | - |
| Voltage Rating： | 50V |
| Operating Temperature： | -25°C ~ 85°C |
| Material Flammability Rating： | UL94 V-0 |
| Current Rating： | 0.2A |
| Other Names： | 502250-5191 |
