22-12-2081的详细信息
| Datasheets： | |
|---|---|
| 22-12-2081： | |
| Product Photos： | |
| 22-12-2081： | |
| Video File： | |
| Molex - Product of the Quarter - Mini-Fit®： | |
| RoHS Information： | |
| 22-12-2081 Cert of Compliance： | |
| Catalog Drawings： | |
| 22 Series Center Front, Top： | |
| 22 Series Center Right Angle Side： | |
| 3D Model： | |
| 22-12-2081.stp： | |
| Standard Package ： | 10 |
| Category： | Connectors, Interconnects |
| Family： | Rectangular Connectors - Headers, Male Pins |
| Series： | KK® 4094 |
| Packaging ： | Bulk |
| Contact Type： | Male Pin |
| Connector Type： | Header, Unshrouded |
| Number of Positions： | 8 |
| Number of Positions Loaded： | All |
| Pitch： | 0.100" (2.54mm) |
| Number of Rows： | 1 |
| Row Spacing： | - |
| Contact Mating Length： | 0.369" (9.37mm) |
| Mounting Type： | Through Hole, Right Angle |
| Termination： | Solder |
| Fastening Type： | - |
| Features： | - |
| Contact Finish： | Gold |
| Contact Finish Thickness： | 20µin (0.51µm) |
| Color： | White |
| Dynamic Catalog： | KK® 4094 Series |
| Mating Products： | WM2817-ND - RCPT .100 RT ANG 8CKT TINWM2618-ND - CONN HSNG 8POS .100 W/RAMP/RIBWM1581-ND - CONN HOUSING 8POS .100 W/O RAMPWM18607-ND - CONN RECPT 8POS .100" 15GOLD PCBWM18596-ND - CONN RECEPT 8POS .100" TIN PCB14-60-0081-ND - CONN IDC 8POS .100 TIN 24AWG14-56-2081-ND - CONN IDC 8POS .100 GOLD 24AWGWM3239-ND - CONN RECEPT 8POS .100 VERT PCBWM3228-ND - CONN RECEPT 8POS .100 VERT PCBWM3217-ND - CONN RECEPT 8POS .100 R/A PCBWM2017-ND - CONN HOUSING 8POS .100 W/RAMPWM2607-ND - CONN HOUSING 8POS .100 HI PRESSWM2806-ND - CONN HOUSING 8POS .100 SINGLEWM3206-ND - CONN RECEPT 8POS .100 VERT PCBWM3106-ND - CONN RECEPT 8POS .100 VERT PCBWM3006-ND - CONN RECEPT 8POS .100 R/A PCBWM2006-ND - CONN HOUS 8POS .100 W/RAMP/RIB |
| Other Names： | 002212208122-12-2081-P22122081WM2739 |
