212510-1的详细信息
| Datasheets： | |
|---|---|
| 212510： | |
| Other Related Documents： | |
| PCB Layout： | |
| 3D Model： | |
| 212510-1.pdf： | |
| Standard Package ： | 300 |
| Category： | Connectors, Interconnects |
| Family： | D-Sub, D-Shaped Connectors - Housings |
| Series： | AMPLIMITE 109, AMP |
| Packaging ： | Bulk |
| Connector Style： | D-Sub, Combo |
| Connector Type： | Receptacle for Female Contacts |
| Number of Positions： | 17 (15 + 2 Coax or Power) |
| Number of Rows： | 2 |
| Shell Size, Connector Layout： | 3 (DB, B) - 17W2 |
| Contact Type： | Signal and Coax or Power |
| Mounting Type： | Free Hanging (In-Line) |
| Flange Feature： | Housing/Shell (Unthreaded) |
| Features： | - |
| Shell Material, Finish： | Steel, Cadmium Plated |
| Shell Finish Thickness： | - |
| Note： | Contacts Not Provided |
| Ingress Protection： | - |
| Operating Temperature： | - |
| Mating Cycles： | - |
| Dielectric Material： | Polyester, Glass Filled |
| Color： | Blue |
| Mating Products： | 5-212506-5-ND - CONN D-SUB PLUG HSING 17C2 MIX212506-1-ND - CONN D-SUB PLUG HSING 17C2 MIX |
| Associated Product： | 1218267-3-ND - CONN D-SUB SKT 20-24AWG CRIMP AU1218267-1-ND - CONN D-SUB SOCKET 18AWG CRIMP AU445798-1-ND - CONN D-SUB SKT SOLDER AU SZ8445548-1-ND - CONN D-SUB SKT SOLDER AU SZ8A34791-ND - CONN SOCKET COAX SIZE8 RG142/400A34790-ND - CONN SOCKET COAX SIZE8 RG179/187A34789-ND - CONN SOCKET COAX SIZE8 RG174/188A34798-ND - CONN SOCKET 10AWG CRIMP GOLD1-208778-1-ND - CONTACT SOCKET .46" DIA POSTEDA34467-ND - CONTACT SOCKET 20-24AWG CRIMPA34800-ND - CONN SOCKET 16-18AWG CRIMP GOLD228596-4-ND - CONN SOCKET STR SIZE 8 RG142,400228596-2-ND - CONN SOCKET STR SIZE 8 RG179,187A34797-ND - CONN SOCKET 8 AWG GOLD CRIMP205090-2-MIL - CONN SOCKET 20-24AWG CRIMP GOLD206793-1-ND - SZ 20,SOCKET, NON-MAGA34799-ND - CONN SOCKET 12-14AWG CRIMP GOLD1-208778-0-ND - CONN D-SUB CONTACT 20POS GOLD228596-1-ND - CONN SCKT COAXI SIZE8 RG/U CABLEA2161-ND - CONN D-SUB SOCKET 20-24AWG AU |
