212491-7的详细信息
| Datasheets： | |
|---|---|
| 212491： | |
| RoHS Information： | |
| 212491-7 Statement of Compliance： | |
| RoHS 2 Statement： | |
| 3D Model： | |
| 212491-7.pdf： | |
| Standard Package ： | 50 |
| Category： | Connectors, Interconnects |
| Family： | D-Sub, D-Shaped Connectors - Housings |
| Series： | Military, MIL-DTL-24308, AMPLIMITE 109, AMP |
| Packaging ： | Bulk |
| Connector Style： | D-Sub, Combo |
| Connector Type： | Plug for Male Contacts |
| Number of Positions： | 5 (Coax or Power) |
| Number of Rows： | 1 |
| Shell Size, Connector Layout： | 3 (DB, B) - 5W5 |
| Contact Type： | Coax or Power |
| Mounting Type： | Free Hanging (In-Line) |
| Flange Feature： | Housing/Shell (Unthreaded) |
| Features： | - |
| Shell Material, Finish： | Brass, Gold Plated |
| Shell Finish Thickness： | - |
| Note： | Contacts Not Provided |
| Ingress Protection： | - |
| Operating Temperature： | - |
| Mating Cycles： | - |
| Dielectric Material： | Polyester, Glass Filled |
| Color： | Blue |
| Mating Products： | 212059-6-MIL - CONN RCPT 5C5POS SER 109 COAX |
| Associated Product： | 213062-1-ND - CONN D-SUB PIN SOLDER AU SZ8A34788-ND - CONN PIN COAX RG142/BELDEN 9246A34787-ND - CONN PIN COAXIAL RG-179/187A34786-ND - CONN PIN COAXIAL RG-174/188/316A34794-ND - CONN PIN 10AWG CRIMP GOLD449379-1-ND - CONN CONTACT PIN PCB #8A34796-ND - CONN PIN 16-18AWG CRIMP GOLDA34795-ND - CONN PIN 12-14AWG CRIMP GOLDA34793-ND - CONN PIN 8 AWG CRIMP GOLD449379-2-ND - CONN CONTACT PIN GOLD228618-4-ND - CONN PIN COAX RG142/BELDEN9246228618-2-ND - CONN PIN STRAIGHT 30AU COAXIAL228618-1-ND - CONN PIN COAXIAL STRAIGHT GOLD |
| Other Names： | 212491-7-ND311P405-10P-B-15311P405-10P-B-15-MIL |
