2-1840026-1的详细信息
| Datasheets： | |
|---|---|
| 1840026 Drawing： | |
| Product Training Modules： | |
| Integrated Connector Module： | |
| Standard Package ： | 36 |
| Category： | Connectors, Interconnects |
| Family： | Modular Connectors - Jacks With Magnetics |
| Series： | Mag45 |
| Packaging ： | Bulk |
| Connector Type： | RJ45 with USB A, Dual |
| Number of Ports： | 3 |
| Number of Rows： | 3 |
| Applications： | 10/100 Base-T, AutoMDIX |
| Mounting Type： | Through Hole |
| Orientation： | 90° Angle (Right) |
| Termination： | Solder |
| Height Above Board： | 1.170" (29.72mm) |
| LED Color： | Green - Green |
| Number of Cores per Jack： | 4 |
| Shielding： | Shielded, EMI Finger |
| Features： | Board Lock, Decoupling Capacitance |
| Tab Direction： | Up |
| Contact Material： | Phosphor Bronze |
| Contact Finish： | Gold |
| Contact Finish Thickness： | 30µin (0.76µm) |
| Shield Material： | Brass |
| Housing Material： | Thermoplastic |
| Operating Temperature： | 0°C ~ 70°C |
