19418-0023的详细信息
| Datasheets： | |
|---|---|
| 19418-0023： | |
| MX150L Overview： | |
| Transportation Catalog： | |
| Product Photos： | |
| 19418-0022,19418-0023： | |
| RoHS Information： | |
| 19418-0023 Cert of Compliance： | |
| Catalog Drawings： | |
| 19418 Series Dual Recept： | |
| 3D Model： | |
| 19418-0023.stp： | |
| Standard Package ： | 10 |
| Category： | Connectors, Interconnects |
| Family： | Rectangular Connectors - Housings |
| Series： | MX150L™ 19418 |
| Packaging ： | Bulk |
| Connector Type： | Receptacle |
| Contact Type： | Female Socket |
| Number of Positions： | 8 |
| Pitch： | 0.230" (5.84mm) |
| Number of Rows： | 2 |
| Row Spacing： | 0.236" (6.00mm) |
| Mounting Type： | Free Hanging (In-Line) |
| Contact Termination： | Crimp |
| Fastening Type： | Latch Holder |
| Color： | - |
| Features： | IP67 |
| Note： | Contacts Not Provided |
| Dynamic Catalog： | MX150L™ |
| Kits： | WM1044-ND - KIT CONN MX150L SERIES |
| Mating Products： | 0194350819-ND - PLUG 8CKT SEAL PNL MNT 22-18AWG0194350814-ND - 8POS PLUG PNL MNT 22-18 NO GSKT0194350813-ND - 8POS PLUG PNL MNT 14-16 NO GSKT0194350812-ND - 8POS PLUG PNL MNT 22-18 W/GSKT0194350811-ND - 8POS PLUG PNL MNT 14-16 W/GSKT0194290045-ND - 8-WAY PLUG T/H PANEL MT W/SEALWM9885-ND - 8-WAY PLUG PANEL MT W/SEAL0194290029-ND - 8-WAY PLUG T/H PANEL MNT0194290011-ND - 8-WAY PLUG PANEL MNTWM17512-ND - CONN HEADER 8POS VERTIAL TINWM17507-ND - CONN HEADER 8POS RIGHT ANGLE TINWM17424-ND - CONN PLUG 8POS 14-16AWG DUALWM17423-ND - CONN PLUG 8POS 18-22AWG DUAL |
| Associated Product： | 0194200003-ND - CONN FEMALE TERM 16-14AWG GOLDWM7029CT-ND - CONN SOCKET TERM 14-16AWG TINWM7029TR-ND - CONN SOCKET TERM 14-16AWG TINWM17431-ND - CONN KEYING PLUG FOR MX SERIESWM17428-ND - CONN TERM FEMALE 14-16AWG TIN |
| Other Names： | 019418-0023019418-0023-P01941800230194180023-P19418-0023-P194180023194180023-PWM17414 |
