172-E37-211-031的详细信息
| Product Photos： | |
|---|---|
| 172-E37-211R031,172-E37-211-031： | |
| Catalog Drawings： | |
| 170 Series Front： | |
| Footprint 9,15,25-,37 Position： | |
| 171, 172 Series Dip Solder： | |
| Featured Product： | |
| M-SERIES D-Sub Connectors： | |
| Standard Package ： | 30 |
| Category： | Connectors, Interconnects |
| Family： | D-Sub Connectors |
| Series： | 172-E |
| Packaging ： | - |
| Connector Style： | D-Sub |
| Connector Type： | Receptacle, Female Sockets |
| Number of Positions： | 37 |
| Number of Rows： | 2 |
| Shell Size, Connector Layout： | 4 (DC, C) |
| Contact Type： | Signal |
| Mounting Type： | Through Hole |
| Flange Feature： | Mating Side (4-40) |
| Termination： | Solder |
| Features： | - |
| Shell Material, Finish： | Steel, Yellow Chromate Plated |
| Contact Finish： | Gold |
| Contact Finish Thickness： | Flash |
| Ingress Protection： | - |
| Operating Temperature： | -50°C ~ 100°C |
| Voltage Rating： | - |
| Current Rating： | 5A |
| Housing Material： | Polybutylene Terephthalate (PBT) |
| Color： | White |
| Mating Products： | 1137MER-ND - CONN DB37 MALE SOLDER CUP TIN1137MEA-ND - CONN DB37 MALE SOLDER CUP NKL1137MA-ND - CONN DB37 MALE SOLDER CUP TIN |
| Other Names： | 19E09F19E09F-ND7537FE |
