型号:

104031-0811

厂商: Molex Molex
标准:
分类: 连接器存储器连接器
描述: memory card connectors micro SD push-pull smt 1.42mm height
报错 收藏

Datasheet下载地址

本地下载 >> 第三方平台下载 >>

104031-0811的详细信息

Manufacturer: Molex
Product Category: Memory Card Connectors
RoHS: Yes
Brand: Molex
Product: Card Connectors
Card Type: microSD
Pitch: 1.1 mm
Orientation: Right Angle
Termination Style: SMD
Number of Rows: 1
Number of Contacts: 8
Current Rating: 500 mA
Voltage Rating: 10 VAC/DC
Contact Material: Phosphor Bronze
Features: Detect Switch
Flammability Rating: UL 94 V-0
Height: 1.42 mm
Housing Material: Liquid Crystal Polymer (LCP)
Insertion - Extraction Style: Push-Pull
Length: 11.4 mm
Mating Cycles: 10000
Mounting Type: Standard
Packaging: Reel
Series: 104031
Factory Pack Quantity: 10000
Tail Length: 0.95 mm
