1-1393115-6的详细信息
| Datasheets： | |
|---|---|
| KUIP, KUGP Series： | |
| Product Photos： | |
| 1-1393115-6： | |
| Standard Package ： | 25 |
| Category： | Relays |
| Family： | Power Relays, Over 2 Amps |
| Series： | KUIP, Potter & Brumfield |
| Packaging ： | Bulk |
| Relay Type： | General Purpose |
| Coil Type： | Non Latching |
| Coil Current： | 100mA |
| Coil Voltage： | 12VDC |
| Contact Form： | 3PDT (3 Form C) |
| Contact Rating (Current)： | 10A |
| Switching Voltage： | 240VAC - Max |
| Turn On Voltage (Max)： | 9 VDC |
| Turn Off Voltage (Min)： | - |
| Operate Time： | 20ms |
| Release Time： | 15ms |
| Features： | Insulation - Class B |
| Mounting Type： | Socketable |
| Termination Style： | Plug In, Quick Connect - 0.187" (4.7mm) |
| Contact Material： | Silver Cadmium Oxide (AgCdO) |
| Coil Power： | 1.2 W |
| Coil Resistance： | 120 Ohms |
| Operating Temperature： | -45°C ~ 95°C |
| Dynamic Catalog： | KUIP Series |
| Associated Product： | 27E305-ND - SOCKET NYL FOR KU SER PCBPB810-ND - SOCKET RELAY 1-3 POLES QCPB797-ND - SOCKET SP-3P KU SERIESPB639-ND - SOCKET SOLDER FOR KU RELAYSPB522-ND - SOCKET PCB TERMINAL KU SERIESPB165-ND - SOCKET RELAY SCREW TERM KU |
| Other Names： | 1-1393115-6-ND113931156KUIP-14D15-12KUIP-14D15-12-NDPB1462 |
