Molex
0834229014的详细信息
| Datasheets： | |
|---|---|
| 0834229014： | |
| Product Photos： | |
| 0834229014： | |
| RoHS Information： | |
| 834229014 Cert of Compliance： | |
| 3D Model： | |
| 83422-9014.stp： | |
| Standard Package ： | 100 |
| Category： | Connectors, Interconnects |
| Family： | D-Sub, D-Shaped Connectors - Housings |
| Series： | Commercial Micro-D Series 83422 |
| Packaging ： | Bulk |
| Connector Style： | D-Type, Micro-D |
| Connector Type： | Receptacle for Female Contacts |
| Number of Positions： | 15 |
| Number of Rows： | 2 |
| Shell Size, Connector Layout： | 0.050 Pitch x 0.050 Row to Row |
| Contact Type： | Signal |
| Mounting Type： | Free Hanging (In-Line) |
| Flange Feature： | Cable Side |
| Male Jackscrew (2-56)： | |
| Features： | Assembly Kit, Shielded |
| Shell Material, Finish： | Steel, Nickel Plated |
| Shell Finish Thickness： | - |
| Note： | Contacts Not Provided |
| Ingress Protection： | - |
| Operating Temperature： | -40°C ~ 125°C |
| Mating Cycles： | 500 |
| Dielectric Material： | Liquid Crystal Polymer (LCP) |
| Color： | - |
| Dynamic Catalog： | Commercial Micro-D Series |
| Mating Products： | 0836129205-ND - CMD VERT 15POS PLUG PCB0836129203-ND - 15PIN RT ANG CMD PLUG PCB0836129201-ND - 15PIN RT ANG CMD HEADER PCB0836129022-ND - CMD R/A 15POS PLUG PCBWM2143-ND - CONN PLUG MICRO-D 15POS R/A PCB |
| Associated Product： | 0621004102-ND - STATIONARY FORM TOOL 15 POS0621004101-ND - MOVING FORM TOOL 15 POS0622019800-ND - ARBOR PRESS W/TOOLING 15CKT0830009503-ND - CONN SOCKET TERM 26-28AWG CRIMPWM4332-ND - CMD SOCKET TERMINALSWM3565TR-ND - CMD SOCKET TERMINALS |
| Other Names： | 083422-901483422-9014834229014WM3568 |
