Molex
0399200311的详细信息
| Datasheets： | |
|---|---|
| 0399200311 Drawing： | |
| RoHS Information： | |
| 399200311 Cert of Compliance： | |
| 3D Model： | |
| 39920-0311.stp： | |
| Standard Package ： | 20 |
| Category： | Connectors, Interconnects |
| Family： | Terminal Blocks - Wire to Board |
| Series： | Eurostyle™ 39920 |
| Packaging ： | Bulk |
| Number of Levels： | 1 |
| Positions Per Level： | 11 |
| Pitch： | 0.591" (15.00mm) |
| Mating Orientation： | Horizontal with Board |
| Current： | 115A |
| Voltage： | 600V |
| Wire Gauge： | 1-8 AWG |
| Mounting Type： | Through Hole |
| Wire Termination： | Screw - Rising Cage Clamp |
| Features： | - |
| Color： | Black |
| Operating Temperature： | -40°C ~ 130°C |
| Housing Material： | Thermoplastic |
| Contact Material - Plating： | Copper - Tin Plated |
| Clamp Material - Plating： | Brass - Nickel Plated |
| Screw Material - Plating： | Bronze - Tin Plated |
| Torque - Screw： | 3.95 Nm (35 Lb-In) |
| Screw Thread： | 1/4-28 |
| Other Names： | 039920-031139920-0311399200311 |
